DXP is the digital radio based on European Standard dPMR incorporating with
AMBE vocoder that supports high quality voice. This digital radio can be possible
to provide equal,staticless and clear voice-quality regardless of distance,
is able to do the Caller ID similar to a telephone and also, at the same time,
can communicate securely for private talk without any worrieness that the other
eavesdrops on your conversation. Those kind advantages from the digital have us
to be able to establish wireless networks more effectively.
So,it should attribute maximizing work-efficiency to industries, mega shopping malls,
leisure and recreations.
- Mechanical structure designed to appropriate to rough and harsh working environment
- Compact and ergonomic design for conveience to carry and use
- Applied the 2.00mm thickness special PCB
- Applied the Wide-head volume knob
- High strength Frame
- Clear and strong volume speaker
- High capacity battery pack to have long duration
- 1024 Channels / 32 Group
- 6.25/12.KHz Channel spacing
- Analog/Digital combined possible
- Button programmable
- LCD contrast controllerble
- Key-tone controllerble
- Hi/Low power convertable
- PASSWORD
- DTMF
- Scan/Priority Scan
- VOX (Automatic PTT)
- TOT
- Monitor
- Over 50,000 encryption codes
- Lone worker
- EMERGENCY
- Stun/Survive
- Lettering
- Pre-memorized SMS
- OTA Channels and ID sending
- 53 CTCSS
- 208 DCS
 |
 |
||
|---|---|---|---|
 |
 |
 |
|
| Frequency range | 138~174MHz | 216~223MHz | 400~470MHz |
| Frequency Stability | + / - 1.5ppm | ||
| No of Channels & Groups | 1024 / 32 | ||
| Channel Spacing | Digital: 6.25kHz Analog: 12.5kHz | ||
| Demension(W x H x D) | 51 x 104.5 x 32.5mm | ||
| Weight | 270g (Including a antenna and a battery pack) | ||
| Operating Temperature | -30℃ / +60℃ | ||
| Power source | + 7.4V Li-Ion 2,600mAh Battery | ||
| Modulation Type | Analog : 8K50F(G)3E Digital : 4K00F1D, 4K00F1E |
||
Transmitter
| Output Power | Low : 2 Watt High : 5Watt |
| Frequency Deviation | Analog:+/-2.5Khz @ 12.5Khz Digital: +/-1.75Khz@6.25 |
| Hum & Noise Ratio | >35dB |
| Conducted Spurious Emission | >65dB |
| Adjacent Channel Power Ratio | >60dB |
Receiver
| Sensitivity | Digital: < 1% BER (@6dBuV emf(-107dBm)) |
| Analog> 0.25uV (-119dBm) at 12dB SINAD | |
| Adjacent Channel Selectivity | Digital: >55dB Analog: >60dB |
| Sprious Response Rejection | Digital: >70dB Analog: >70dB |
| Max Audio Power | > 1.5Watt (16ohm) |
| Audio Distortion | < 5% |
